Description
Our customers wanted to produce a 180° wrap quickly, more efficiently, and wrap all the way around with only one seam on the backside. To meet that need, we designed the Slotformer®.
The Slotformer® is the quickest, easiest, and least expensive method of obtaining a full wrap-around. In a matter of minutes, an inexperienced operator can learn how to produce 180° wraps.
You can bend all formable high-pressure laminates from the thicker countertop materials to the thinner cabinet and surfacing materials, as well as real wood veneers. Ninety-degree bends, no drip edges and a multitude of other shapes can also be formed easily on this machine. This product will produce hundreds of wraps per day and will make money for your company.
The rear platen is adjustable down from 6-1/4” to whatever diameter rolled edge is desired. On Model SF-12, the front and lower pressure platens are divided at the center to allow for individual operation. A switch on the control panel marked 12 ft. / 6 ft. selects the mode required. Located along the SF-12 front edge are left and right-hand switches. In the 6 ft. mode, each switch operates the left or right pressure platens respectively. In the 12 ft. mode, either switch operates the entire pressure length. The rear adjustable platen and Dual Quartz Heater remain full length during all operations. On both models, the lower pressure platen need not be activated when doing 180° full wraps and may be turned off as required.
Model SF-12 is 150” long, 26” wide, and 30” high. The Dual Element Quartz Heater included, is 157” long and 6” wide. A simple connection is provided for the 208/230 volt, 1 phase 40 amps power. An air regulator and gauge is located on the equipment for easy access. One 2oz. Bottle of Tempilaq is included along with complete instructions on both models.
Model SF-6 is 78” long with all the features of the 12 ft. model and is designed for those who do not require a divided front platen. Power requirements for the 6 ft. model are 208/230 volt, 1 phase, and 30 amps.
All equipment comes with a limited one-year warranty.
